FX-BPSB: Single Box Cotton Fibre Bailing Press

SEED PROCESSING

Ferro cotton baling press is designed for compressing cotton of different grades.
Reengineered Friendly design to Facilitate easy operation low power consumption & requiring minimum labor cost.
Provision of proximity sensors, limits switches, check valves etc. which helps in avoiding any accident.
Ferro bailing press can be customized as per requirement under the side discretion of Ferro Oiltek.
Ferro bailing press comes with an advantage of multiple pushers as well as single pusher as per requirement of the customers.
Parts of the press are standardized as per international standards.
Extremely robust body structure provides zero vibration.
ADVANCED PU COAT FINISH for easy cleaning, long lasting appeal & great aesthetics.

OPERATION OF BAILING PRESS :

Redesigned lint box & pusher rollers for easy maintenance CNC machined parts for high precision.
Compactly designed machine, which helps in saving valuable space as well as easier for machine operation.
Easy Animated HMI PLC operation system makes it easy to operate Capable of delivering high speed operation support.
Capable of delivering high speed operation support.
Option of twin pusher makes the operation Fast.

Main ram : Rod Dia – 180 mm (stroke 2580mm)
Lint box lifting cylinder : Rod Dia – 60mm (2 no’s) (stroke 1150mm)
Election cylinder : Rod Dia 30mm (stroke 140mm)
Installed power (HP) : Main motor-40 hp x 1500 rpm Auxiliary motor -10 HP X 1500 rpm
Hydraulic pump : Main pump -Double valve pump (35 gpm & 12gpm) Auxiliary pump -12 gpm.
Bale size : 55″ X 21″ X 28″/ 48″ X 18″ x 18″
Bale weight: 220 kg / 180 Kg
Bale density: Universal / High
Operating: PLC panel (Fully Automatic)
Shed size: 14M X 12M X 12M
Production capacity: 6-9 bales per hour
Pusher: Hydraulic
