PREPARATORY
Cooker
The objective of cooker conditioning is to obtain the best conditions prior to flaking.
Read More
PREPARATORY
MECHANICAL EXPELLER
The Ferro Expeller is a self-contained unit which has its own heating kettle or conditioner and an arrangement for automatic feeding. The expeller requires no attention after setting so long as proper temperature and moisture content of the seed meal is regulated.
Ferro Expeller is suitable for small, medium as well as large scale plant. Our machinery is known for its high oil extracting efficiency and being highly advanced for easy to use and continuous operation.
Our Expellers are capable to process variety of seeds and nuts such as Cotton seeds, Mustard seeds, Sunflower seeds, Soyabean and many more.
- Low Equipment cost using high torque mechanism
- Low power consumption with the help of frequency converter
- Harden face worms of special alloy steel
- Instantly consumable crude oil production
- Oil has better nutritive properties.
- Ferro Expeller can be used for expelling oil out of variety of seeds just by applying few changes in machinery such as gap between the cage bars, conditioning of inlet meat, etc as suitable for the seed.
- Efficient power consumption by the Expeller motor providing suitable required torque.
- Rigid and Steady body for the machine as it generates high force while pressing.
- High grade steel worms are used, as it plays important role in satisfactory extraction of different oil seeds.
|
Sr No |
Model |
Full Press |
Power |
RPM |
|
1 |
FEXP 801 |
2-2.5TPD |
10HP |
18-24 |
|
2 |
FEXP 802 |
5-6TPD |
20HP |
18-24 |
|
3 |
FEXP 803 |
15-18TPD |
40HP |
18-24 |
|
4 |
FEXP 804 |
20TPD |
50HP |
18-24 |
|
5 |
FEXP 805 |
20-25TPD |
75HP |
18-24 |
|
6 |
FEXP 806 |
30-35TPD |
100HP |
18-24 |
|
7 |
FEXP 807 |
40-45TPD |
125HP |
18-24 |
|
8 |
FEXP 808 |
50-60TPD |
170HP |
18-24 |
