Pneumatic Closed Type Seed Cleaner is a uniquely designed machine with 8 stage basket beater which is used for getting maximum cleaning efficiency and minimizing the wear and tear for ease of removability & changeability.
Cottonseed cleaner is the complete unit is designed to remove foreign material effectively and all type of impurity from white cottonseed.
We provide special stone separator & vacuum feeder for seed cleaning operation.
This machine used to produce clean seeds with higher cellulose, these cleaned seeds further obtained for De-linting & Dehulling operation.
Seed cleaner separates un-ginned cotton, stones, metal pieces, dust and fine impurities from seed with 99% clean seeds at the end.
Because of adroit seed cleaning other processing machines like Delinters & Hullers get protected.
Due to better cleaning efficiency. quality of bi-products of cottonseeds increases likes cotton linters and DOC.
Application: Cotton Seed, Soya Seed, Sunflower Seed, Groundnut Seed, Cocoa Seed etc.. Modification in the machine will be needed for different types of Seed.
The vacuum chamber is specially designed for easy operation & maintenance.
The baskets are been designed for easy opening and closing operations, in order to clean them periodically while operations.
Zero speed sensors are provided at the end of the last beater to detect the chain breakage and avoid choking of the machine.
Soft Starters & Harden SKF Sprocket for beater drives, for higher durability and least maintenance.
The seed first enters to a pneumatic chamber through a rotary feeder, as soon as sees reside in the zigzag, the pneumatic suction will lift the seed. The suction is adjusted only to lift the seed leaving the heavier impurities like stones, metal parts etc. will drop down.
There after seeds forwarded to seed cleaner beater section through dropper cyclone, after beating operation, at the end of beater section we get un-gin cotton.
Remaining seed drop through the hopper on shaker tray & here we are separating dust, fine impurities from seed then conveying to outside, after shaking operation done clean seeds move forward through the bottom conveyor to next operation i.e. De-linting operationor direct dehulling.
FEEDER MOTOR 1HP/4 POLE
BEATER MOTOR 10HP/8 POLE
CONVEYOR GEAR MOTOR 2HP/4 POLE
TRAY MOTOR 2HP/4 POLE
STONE SEPARATOR FEEDER 1HP/4 POLE
VACUUM FEEDER 2HP/4 POLE
36″ BLOWER 25HP/ 4 POLE
