FX-PCAC: Air Cascade Pre-Cleaner
This machine is a combination of density separator and basket beater separator for better Read More
The Ferro Air Cascade Pre-Cleaner is designed to remove the ﬂy dust and fuzziness of seed with a gentle air wash at Zig-Zag cascade. It is capable of separating ﬂy dust from the seed and all lighter than seed impurities, which can result in poor quality linters if not separated. Thanks to efﬁcient cascade, which not only helps for producing quality linters but also reduce the dust in the plant.
The seed will be feed through a rotary feeder into Air Cascade. The aspiration system from top will help the seed for an air wash and to lift the lighter impurities from the top, and drop the clean seed into the conveyor below. The lifted impurities will be collect to a dust cyclone.
1) FEEDER MOTOR - 1HP/4 POLE
2) ZIG-ZAG BLOWER - 24” 10 HP/4 POLE
